Engine
Engine Type: 4-Stroke, SOHC, Air Cooled Displacement: 271.3 cc Bore*Stroke: 75.0 × 61.4 mm Compression Ratio: 9.29:1 Max Power: 16.0 kw @ 8500 rpm Max Torque: 22.0 N⋅m @ 6500 rpm Fuel System: Carburetor Starting: Electric Transmission: Manual Five Speed with 1-N-2-3-4-5 Ignition: CDI
Chasis
Frame: High strength steel tube frame Front shock: 880 mm Adjustable Rear shock: 450 mm Adjustable Front Braking: Disc Brake Rear Braking: Disc Brake Front Wheel Rim: 1.60×21 Rear Wheel Rim: 2.15×18
Dimensions and Capacities
Vehicle Size: 2087 x 808 x 1235 mm Wheelbase: 1425 mm Seat Height: 925 mm Ground Clearance: 316 mm Dry Weight: 112.4 kg Fuel Capacity: 10.0 L
